SKU: KN26B-RODL-48-BN

Rove DL - Road / Gravel

In Transit Stock

External Stock: 0x Units

External Stock: 0x Units

External Stock: 0x Units

External Stock: 0x Units

External Stock: 0x Units

External Stock: 0x Units

Vendor Kona
Size:

Spec Highlights

  • Full Cromoly frame and fork w/ 12mm thru-axles
  • Graduated wheel sizing: 48–52cm 650x47c, 54–58cm 700x40c
  • Shimano CUES 1x11sp drivetrain & hydraulic flat mount brakes w/180mm rotors
  • Kona Gravel handlebars w/ 16o flare
  • WTB Volt saddle
  • WTB ST i23 rims w/Maxxis Rambler TR tires

SPECIFICATIONS

Frame Material Kona Butted Cromoly
Sizes 48, 50, 52, 54, 56, 58
Rear Shock n/a
Fork Kona Project Two Cromoly Disc
Crankarms Shimano CUES
Chainrings 40t
B/B Shimano BB68
Pedals n/a
Chain Shimano CUES
Cassette Shimano CUES 11-50t 11spd
Chainguide n/a
F/D n/a
R/D Shimano CUES 11spd
Shifters Shimano CUES
Brake Calipers Shimano CUES
Front Brake Rotor Shimano RT54 160mm Centerlock
Rear Brake Rotor Shimano RT54 160mm Centerlock
Brake Levers Shimano CUES
Headset FSA No.1/No.10
Handlebar Kona Gravel Dropbar
Stem Kona Gravel
Seatpost Kona Thumb w/Offset 27.2mm
Seat Clamp Kona Clamp
Grips Kona Cork Tape
Saddle WTB Volt
Front Hub Shimano 105 Road TA 100x12mm Centerlock
Rear Hub Shimano 105 Road TA 100x12mm Centerlock
Spokes Stainless Black 14g
Rims WTB ST i23 TCS 2.0
Front Tire Maxxis Rambler EXO 650x47c (48c,50c,52c) / 700x40c (54c,56c,58c)
Rear Tire Maxxis Rambler EXO 650x47c (48c,50c,52c) / 700x40c (54c,56c,58c)
Paint Color Gloss Mocha w/ Orange & Black Decals
All specifications are subject to change without notice.

GEOMETRY

Size 48 50 52 54 56 58
1 ST Length 480 500 520 540 560 580
2 TT Length 515 531 546 562 578 598
3 Reach 372 378 383 388 392 400
4 Stack 532 551 570 588 607 626
5 Standover 737 755 777 807 828 847
6 HT Angle 70.5 70.5 71.0 71.0 71.5 71.5
7 HT Length 90 110 130 150 170 190
8 ST Angle 75.0 74.5 74.0 73.5 73.0 72.5
9 CS Length 435 435 435 435 435 435
10 BB Drop 74 74 72 72 70 70
11 BB Height 270 270 272 284 286 286
12 Wheelbase 1016 1029 1036 1048 1054 1068
13 Front Center 592 604 612 623 628 643
14 Fork Length 410 410 410 410 410 410
15 Fork Offset 50 50 50 50 50 50
Bike Geometry
