Hei Hei G9 - Full Suspension

Name: Hei Hei G9 - Full Suspension
Brand: Kona
SKU: KN23B-HH-SM-RW
Price: 1399.0 GBP
Availability: InStock

In Transit Stock

External Stock: 0x Units

Kona

If we had to sum up the Hei Hei in one sentence it would be this: The Hei Hei is fast, fun, easy to ride, climbs like a mountain goat, descends like a cheetah, is affordable, has no frills but everything you need with its 120mm of front and 100mm of rear travel, and will ensure that you end every ride with a smile on your face. Run on sentences aside, the Hei Hei has been in our lineup for decades because it’s one of the best bikes we’ve ever made. It blurs the line between XC and trail bike and has proved that great ideas evolve into bikes with staying power.

SPEC HIGHLIGHTS

RockShox SID 35 120mm fork
Monarch RL 100 mm rear shock
Travel-adjust TranzX dropper post
Shimano SLX/Deore 1x 12spd drivetrain with 10-51t cassette or SRAM NX Eagle 12sp drivetrain with 11-50t cassette
Shimano MT410 or SRAM Level T brakes

B35HH01

B35HH03

B35HH05

B35HH06

SPECS & GEOMETRY

SPECIFICATIONS

FRAME MATERIAL	Kona Race Light 6061 Aluminum Butted 100mm Travel
SIZES	S, M, L, XL
REAR SHOCK	RockShox Monarch RL Solo Air
FORK	RockShox SID 35 DebonAir 120mm Tapered 110mm Spacing
CRANKARMS	Shimano 12spd
CHAINRINGS	32t
B/B	Shimano PF92
PEDALS	n/a
CHAIN	Shimano Deore 12spd
CASSETTE	Shimano Deore 10-51t 12spd
CHAINGUIDE	n/a
F/D	n/a
R/D	Shimano SLX
SHIFTERS	Shimano Deore 12spd
BRAKE CALIPERS	Shimano MT410
FRONT BRAKE ROTOR	Shimano RT30 180mm (centerlock)
REAR BRAKE ROTOR	Shimano RT30 160mm (centerlock)
BRAKE LEVERS	Shimano MT410
HEADSET	FSA No.57B
HANDLEBAR	Kona XC/BC 35
STEM	Kona XC/BC 35
SEATPOST	TranzX Dropper +RAD Internal 31.6mm
SEAT CLAMP	Kona Clamp
GRIPS	Kona Key Grip
SADDLE	WTB Volt
FRONT HUB	Shimano 110x15mm (centerlock)
REAR HUB	Shimano 148x12mm (centerlock)
SPOKES	Stainless Black
RIMS	WTB ST i27 TCS 2.0
FRONT TIRE	Maxxis Forekaster EXO TR DUAL 29x2.35"
REAR TIRE	Maxxis Forekaster EXO TR DUAL 29x2.35"
PAINT COLOR	Matte Faux Raw w/ Metallic Mint & Silver Decals
EXTRAS	n/a

All specifications are subject to change without notice

GEOMETRY

	SIZE	S	M	L	XL
1	ST LENGTH	370	420	470	530
2	TT LENGTH	582	610	639	677
3	REACH	415	440	465	500
4	STACK	593	602	612	621
5	STANDOVER	751	752	761	783
6	HT ANGLE	67.5	67.5	67.5	67.5
7	HT LENGTH	95	105	115	125
8	ST ANGLE	74.2	74.2	74.2	74.1
9	CS LENGTH	430	430	430	430
10	BB DROP	36	36	36	36
11	BB HEIGHT	339	339	339	339
12	WHEELBASE	1129	1158	1187	1226
13	FRONT CENTER	702	731	759	798
14	FORK LENGTH	526	526	526	526
15	FORK OFFSET	51	51	51	51
